10.5.2 CPG1500 with protective case cap
10.5.3 Process connections
Ø44,4 [1.75]
Ø36 [1.42]
Ø10 [0.39]
Ø108,4 [4.27]
G 1/2
27
36,8 [1.45]
5 [0.2]
65,3 [2.57]
120,8 [4.75]
116 [4.57]
Process connection G ½
Ø44,4 [1.75]
Ø36 [1.42]
G 1/2
3 [0.12]
20 [0.79]
32.5 [1.28]
35.5 [1.40]
