25WIKA operating instructions pressure transmitter, model IS-3
MM/YYYY country code based on 14095850.02 12/2014 EN/CN
EN
Temperature class T2 T3 T4
Max. medium temperature (°C) 200 195 175 155 135 130 110 105
Max. ambient temperature (°C)
Circular connector M12 x 1
IS-3-*-****-***-*******-*TM2Z**-****
IS-3-*-****-***-*******-*ZM2Z**-****
Bayonet connector
IS-3-*-****-***-*******-*ZO5Z**-****
IS-3-*-****-***-*******-*ZO6Z**-****
IS-3-*-****-***-*******-*TO5Z**-****
IS-3-*-****-***-*******-*TO6Z**-****
Angular connector acc. to
DIN EN 175301-803 A
IS-3-*-****-***-*******-*TA3Z**-****
IS-3-*-****-***-*******-*TAWZ**-****
IS-3-*-****-***-*******-*TAVZ**-****
Field case
Cable gland nickel-plated brass
IS-3-*-****-***-*******-*TFHZ**-****
IS-3-*-****-***-*******-*TFKZ**-****
Field case
Cable gland stainless steel
IS-3-*-****-***-*******-*TFCZ**-****
IS-3-*-****-***-*******-*TFDZ**-****
Field case conduit
IS-3-*-****-***-*******-*TFSZ**-****
IS-3-*-****-***-*******-*TFTZ**-****
IS-3-*-****-***-*******-*TFLZ**-****
IS-3-*-****-***-*******-*TFMZ**-****
40 45 55 70 85 85 100 105
If an associated mating connector from WIKA is used, the max. ambient temperature for the following variants of
electrical connection is reduced:
Circular connector M12 x 1: -20 ... +80 °C
