31Pressure gauges with output signal, optionally for hazardous areas
11297264.05 07/2019 EN/DE
EN
9. Specifications
Models DPGT43.100, DPGT43.160
Pressure limitation
Steady Full scale value
Fluctuating 0.9 x full scale value
Overload safety and
max. working pressure
see the following table
Temperatureeect When the temperature of the measuring system deviates from
the reference temperature (+20 °C): max. ±0.5 %/10 K of full
scale value
Wetted materials
Media chamber with process
connection, venting of the media
chambers, bellows
Stainless steel 316Ti (1.4571)
Pressure element ≤ 0.25 bar: Stainless steel 316L
> 0.25 bar: NiCr alloy (Inconel)
Non-wetted materials
Case, bayonet ring Stainless steel
Movement Brass
Dial Aluminium, white, black lettering
Pointer Aluminium, black
Window Laminated safety glass
Ingress protection per IEC/EN 60529 IP54; option: IP65
Overload safety and max. working pressure
Scale ranges Overload safety in bar
Either side max.
max. working pressure in bar
(static pressure)
Standard Option Standard Option
0 ... 16 to 0 ... 40 mbar 2.5 - 2.5 6
0 ... 60 to 0 ... 250 mbar 2.5 6 6 10
0 ... 400 mbar 4 40 25 40
0 ... 0.6 bar 6 40 25 40
0 ... 1 bar 10 40 25 40
0 ... 1.6 bar 16 40 25 40
0 ... 2.5 to 0 ... 25 bar 25 40 25 40
For further specications see data sheet PV 17.05
