WIKA PGT23.063 User Manual

Pressure gauges with output signal, optionally for hazardous areas4
11297264.05 07/2019 EN/DE
EN
1. General information
1. General information
 The contact pressure gauge described in the operating instructions has been designed
and manufactured using state-of-the-art technology. All components are subject to strin-
gent quality and environmental criteria during production. Our management systems are
certied to ISO 9001 and ISO 14001.
 These operating instructions contain important information on handling the instrument.
Working safely requires that all safety instructions and work instructions are observed.
 Observe the relevant local accident prevention regulations and general safety regulations
for the instrument's range of use.
 The operating instructions are part of the product and must be kept in the immediate
vicinity of the instrument and readily accessible to skilled personnel at any time.
 Skilled personnel must have carefully read and understood the operating instructions
prior to beginning any work.
 The manufacturer's liability is void in the case of any damage caused by using the
product contrary to its intended use, non-compliance with these operating instructions,
assignment of insuciently qualied skilled personnel or unauthorised modications to
the instrument.
 The general terms and conditions contained in the sales documentation shall apply.
 Subject to technical modications.
 Further information:
- Internet address: www.wika.de / www.wika.com
Model Transmitter electronics
for non-hazardous areas
Transmitter electronics
for hazardous areas
Data
sheet
Model Variant
1)
Model Variant
1)
PGT23.063 891.44 1, 3, 4 - - PV 12.03
PGT23.1x0, PGT26.1x0 891.44 1, 3, 4 892.44 2 PV 12.04
PGT43 891.44 1, 3, 4 892.44 2 PV 14.03
PGT43HP 891.44 1, 3, 4 892.44 2 PV 14.07
PGT63HP 891.44 1, 3, 4 892.44 2 PV 16.06
APGT43 891.44 1, 3, 4 892.44 2 PV 15.02
DPGT43 891.44 1, 3, 4 892.44 2 PV 17.05
DPGT43HP 891.44 1, 3, 4 892.44 2 PV 17.13
1) Variant of the output signal
1: 4 … 20 mA, 2-wire, passive, per NAMUR NE 43
2: 4 ... 20 mA, 2-wire, for hazardous areas
3: 0 ... 20 mA, 3-wire
4: 0 ... 10 V, 3-wire
For instruments which are additionally tted with switch contact(s), the following operat-
ing instructions also apply:
- “Pressure gauges with inductive contact model 831, for hazardous areas”,
article number 14320154
- “Pressure gauges with switch contact model 821, 851 or 830 E”,
article number 14057651
