19WIKA operating instructions pressure transmitter, model S-10
1604457.16 09/2017 EN/DE/FR/ES
Measuringrangesandoverloadsafety(absolutepressure)
bar Measuring range 0 ... 0.25 0 ... 0.4 0 ... 0.6 0 ... 1 0 ... 1.6 0 ... 2.5 0 ... 4
Overload safety 2 2 4 5 10 10 17
Measuring range 0 ... 6 0 ... 10 0 ... 16 0 ... 25 0.8 ... 1.2
Overload safety 35 35 80 80 5
psi Measuring range 0 ... 15 0 ... 25 0 ... 50 0 ... 100 0 ... 250
Overload safety 72.5 145 240 500 1,160
Measuringrangesandoverloadsafety(vacuumand+/-measuringrange)
bar Measuring range -0.6 ... 0 -0.4 ... 0 -0.25 ... 0 -0.16 ... 0 -0.1 ... 0 -1 ... 0 -1 ... +0.6
Overload safety 4 2 2 1.5 1 5 10
Measuring range -1 ... +1.5 -1 ... +3 -1 ... +5 -1 ... +9 -1 ... +15 -1 ... +24
Overload safety 10 17 35 35 80 50
psi Measuring range -15 inHg ... 0 -30 inHg ... 0 -30 inHg ... +15
Overload safety 72.5 72.5 145
Measuring range -30 inHg ... +30 -30 inHg ... +60 -30 inHg ... +100
Overload safety 240 240 500
Measuring range -30 inHg ... +160 -30 inHg ... +200 -30 inHg ... +300
Overload safety 1,160 1,160 1,160
