24 WIKAoperatinginstructionstemperaturetransmitterT32.xS
FurtherinformationonthecongurationoftheT32with
thesoftwaretoolsmentionedaboveisavailableon
request.
6.3.2 DD version
ThemodelT32.xStemperaturetransmittercanbeusedwiththe
followingDTMandDDversions.
T32 HART
®
instrument revision
Corresponding DD
(DeviceDescription)
T32 HART
®
DTM
0 Devv0,DDv2 DTM1.0.2
1 Devv1,DDv1 DTM1.0.2
2 Devv2,DDv1 DTM1.0.2
3 Devv3,DDv1 DTM2.0.0.175
6.3.3 HART
®
communicator (HC275, FC375, FC475, MFC4150)
WiththeHART
®
communicatortheinstrumentfunctionsareselected
viavariousmenulevelsandwiththehelpofaspecialHART
®
function
matrix(seechapter6.5"HART
®
congurationtree").
6.4 Connection of FSK modem, HART
®
communicator
WARNING!
■
Themeasuringcircuithastohavealoadofatleast
250Ω.
■
Foralltransmitterswithhazardousareaprotection
observechapter10"Notesformountingandoperating
inhazardousareas".
Thisresistorisalreadyintegratedinmostpowersuppliesavailable
inthemarketandisthereforenotrequiredseparately.Frequentlya
specialconnectionfortheFSKmodemisalreadyavailable.
