WIKA T32. S Series User Manual

GB
11258421.0901/2012GB/D
30 WIKAoperatinginstructionstemperaturetransmitterT32.xS
9. Electrical connections
WARNING!
Observethesafety-technicalmaximumvaluesforthe
connectionofthepowersupplyandthesensors,see
chapter10.3"Safety-technicalmaximumvalues".
Whenworkingonthetransmitters(e.g.installation/removal,
maintenancework)takemeasurestopreventelectrostaticdischarge
fromtheterminals.
WARNING!
Onlycarryoutinstallationinade-energisedstate!
Theconnectedwiresmustbecheckedtoensurethey
areconnectedproperly.Onlywell-securedwirescan
guaranteeafault-freeoperation.
Input
Sensor
Output
4...20mAloop
Forheadmountingandrailmountingcase,connectionclampsfortheHART
®
modemare
available.
9. Electrical connections

WIKA T32. S Series Specifications

General

Brand	WIKA
Model	T32. S Series
Category	Transmitter
Language	English
