WIL-10410-E-05 21 WILDEN PUMP & ENGINEERING, LLC
EXPLODED VIEW & PARTS LISTING
PS8 METAL
PARTS LISTING
*See elastomer chart - Section 9.
1
Air Valve Assembly includes items 2 and 3.
2
Metal Center Block Assembly includes items 11, 12, 14, 15 and 16.
All boldface items are primary wear parts.
Item
Description Qty.
XPS8/AAAAA/
P/N
XPS8/WWAAA/
P/N
XPS8/SSAAA/
P/N
XPS8/SSAAA/…/0070
P/N
AIR DISTRIBUTION COMPONENTS
1 Air Valve Assembly, Pro-Flo
®
SHIFT
1
1 04-2039-01 04-2039-01 04-2039-01 04-2039-01
2 O-Ring (-225), End Cap (Ø1.859” x Ø.139”) 2 04-2390-52-700 04-2390-52-700 04-2390-52-700 04-2390-52-700
3 End Cap 2 04-2340-01 04-2340-01 04-2340-01 04-2340-01
4 Screw, SHC, Air Valve (1/4”-20 x 4-1/2”) 4 01-6000-03 01-6000-03 01-6000-03 01-6000-03
5 Muffler Plate, Pro-Flo
®
SHIFT 1 04-3189-01 04-3189-01 04-3189-01 04-3189-01
6 Gasket, Muffler Plate, Pro-Flo
®
SHIFT 1 04-3509-52 04-3509-52 04-3509-52 04-3509-52
7 Gasket, Air Valve, Pro-Flo
®
SHIFT 1 04-2629-52 04-2629-52 04-2629-52 04-2629-52
8 Center Block Assembly, Pro-Flo
®
SHIFT
2
1 04-3129-01 04-3129-01 04-3129-01 04-3129-01
9 Pilot Sleeve Assembly 1 04-3880-99 04-3880-99 04-3880-99 04-3880-99
10 O-Ring (-009), Pilot Spool Retaining (Ø.208” x Ø.070”) 2 04-2650-49-700 04-2650-49-700 04-2650-49-700 04-2650-49-700
11 Seal, Shaft 2 08-3210-55-225 08-3210-55-225 08-3210-55-225 08-3210-55-225
12 Bushing, Shaft 2 08-3306-13 08-3306-13 08-3306-13 08-3306-13
13 Gasket, Center Block Pro-Flo V™ 2 04-3529-52 04-3529-52 04-3529-52 04-3529-52
14 Seal, Air Control Spool 2 02-3210-55-225 02-3210-55-225 02-3210-55-225 02-3210-55-225
15 Air Control Spool 1 04-3859-03 04-3859-03 04-3859-03 04-3859-03
16 O-ring, (-114) Air Control Spool Retaining (Ø.612” x Ø.103”) 2 04-3879-50 04-3879-50 04-3879-50 04-3879-50
17 Air Chamber, Pro-Flo V™ 2 08-3660-01 08-3660-01 08-3660-01 08-3660-01
18 Screw, HSFHS (3/8”-16 x 1”) 8 71-6250-08 71-6250-08 71-6250-08 71-6250-08
19 Retaining Ring 2 04-3890-03 04-3890-03 04-3890-03 04-3890-03
20 Grounding Screw, (10-32 x .50”) Self Tapping 1 04-6345-08 04-6345-08 04-6345-08 04-6345-08
21 Muffler 1-1/2” NPT 1 04-3518-99R 04-3518-99R 04-3518-99R 04-3518-99R
22 Muffler 1/4” NPT 1 04-3240-07 04-3240-07 04-3240-07 04-3240-07
WETTED PATH COMPONENTS
23 Liquid Chamber 2 08-5000-01 08-5000-02 08-5000-03 08-5000-03P
24 Manifold, Discharge NPT 1 08-5020-01 08-5020-02 08-5020-03 N/A
Manifold, Discharge BSPT 1 08-5020-01-14 08-5020-02-14 08-5020-03-14 N/A
Manifold, Discharge Tri-Clamp 1 N/A N/A N/A 08-5020-03-70P
25 Manifold, Footed Inlet NPT 1 08-5080-01 08-5080-02 08-5080-03 N/A
Manifold, Footed Inlet BSPT 1 08-5080-01-14 08-5080-02-14 08-5080-03-14 N/A
Manifold, Footed Inlet Tri-Clamp 1 N/A N/A N/A 08-5080-03-70P
26 Large Clamp Band Assembly 2 08-7300-08 08-7300-08 08-7300-03 08-7300-03
27 Screw, HHC Large (3/8”-16 x 3”) 4 08-6120-08 08-6120-08 08-6120-03 08-6120-03
28 Large Hex Nut (3/8”-16) 4 08-6450-08 08-6450-08 08-6450-03 08-6671-10
29 Washer, Brass Flat (Ø.392” x Ø.875” x .063”) (not shown) 4 N/A N/A N/A 08-6720-07-70
30 Small Clamp Band Assembly 4 08-7100-08 08-7100-08 08-7100-03 08-7100-08
31 Screw, HHC Small (5/16”-18 x 1-1/2”) 8 08-6050-08 08-6050-08 08-6050-03 08-6050-03
32 Small Hex Nut (5/16”-18) 8 04-6420-08 04-6420-08 04-6400-03 08-6661-10
33 Washer, Brass Flat (Ø.340” x Ø.750” x .063”) (not shown) 8 N/A N/A N/A 08-6700-07-70
GASKETS/VALVE BALLS/VALVE SEATS/VALVE O-RINGS
34 Ball, Valve 4 * * * *
35 Seat, Valve 4 * * * 08-1121-03P
36 O-Ring, (-334) Valve Seat, PTFE Fitted (Ø2.600 x Ø.210) 4 08-1200-55 08-1200-55 08-1200-55 08-1200-55
FULL STROKE RUBBER/TPE/PTFE COMPONENTS
37 Shaft (Rubber) 1 08-3810-09 08-3810-09 08-3810-09 08-3810-09
Shaft (EZ TPE/PTFE) 1 08-3812-03 08-3812-03 08-3812-03 08-3812-03
38 Piston, Inner 2 08-3700-01 08-3700-01 08-3700-01 08-3700-01
39 Diaphragm, Primary 2 * * * *
40 Diaphragm, Back-Up 2 * * * *
41 Piston, Outer 2 08-4550-01 08-4550-02 08-4550-03 08-4550-03P
LW0043 Rev. D
