condenser and disappears through the exhaust hose.
For continuous operation or unattended operating in drying mode, please
connect the attached drain hose to the unit. Condensed water can automatically
run into a bucket or drain.
• Switch off the unit before operating.
• Remove the plug of the water outlet opening and keep it in safe area.
• Securely and properly connect the drain hose. Make sure it is not kinked and
clear of obstruction.
• Place the outlet of hose over a drain or bucket and ensure that water can
freely ow out of the unit.
• Do not submerge the end of hose into water; otherwise it can cause “Air
Lock” in the hose.
TO AVOID WATER SPILLAGE
• As the negative pressure of condensate drain pan is large, tilt the drain hose
downward toward the oor. It is appropriate that the degree of inclination
should exceed 20 degrees.
• Straighten the hose to avoid a trapping water in the hose.
DISASSEMBLY AND CLEANING
CLEANING THE AIR FILTER (EVERY TWO WEEKS)
Dust collects on the lter and restricts the airow. The restricted airow reduces
the efciency of the system and if it becomes blocked it can cause damage to
the unit.
The air lter requires regular cleaning. The air lter is removable for easy
cleaning. Do not operate the unit without an air lter, or the evaporator may be
contaminated.
1. Press POWER button to switch off the unit and unplug the power cord.
2. Remove the lter mesh from the unit.
3. Use a vacuum cleaner to vacuum dust from the lter.
4. Turn the lter over and rinse the air lter under running
water. Let the water run through the lter in the oppo-
site direction of air ow. Set aside and allow the lter to
air dry completely before reinstalling.
