Williams 5009622A - Page 14

14 MONTEREY TOP VENT GAS WALL HEATER
FIGURE B
FIGURE D
FIGURE C
VENT INSTALLED
FRONT PANEL INSTALLED
STUD WALL
CENTERED
14
3  12
STUD WALL
GAS STUB LOCATIONS
STUD WALL
STUD WALL
16
4  716
A
PLUMBERS
TAPE
BW VENT PIPING
CEILING PLATE SPACER
VENT
HOLD DOWN
PLATE
HEADER
FURNACE
SIDE RAIL
BASE PLATE
PANEL
INSTALLING YOUR FURNACE
