30 MONTEREY TOP VENT GAS WALL HEATER
REF.
NO.
REPLACEMENT PART DESCRIPTION
2509622A
2509621A
25H9622A
3509622A
3509621A
35H9622A
1
Face Panel 4915 4915 4915 4915
2
Front Heat Shield 9C216 9C216 9C216 9C216
3
Combustion Chamber 6922 6922 6923 6923
4
Front Shield Deflector 9B199 9B199 9B199 9B199
5
Inner Shield Top 9C152 9C152 9C152 9C152
6
Draft Hood Assembly 9C184 9C184 9C217 9C217
7
Vent Limit Switch P321826 P321826 P322055 P322055
8
Shield Assembly 9C213 9C213 9C213 9C213
9
Header 5902 5902 5902 5902
10
Burner Pan 9B296 9B296 9B296 9B296
11
Manual Spark Igniter P285500 P285500 P285500 P285500
12
Igniter Bracket 7A189 7A189 7A189 7A189
13
Pal Nut P285501 P285501 P285501 P285501
NOT
SHOWN
Header - Insulation P310000 P310000 P310000 P310000
NOT
SHOWN
Parts Bag 9A324 9A325 9A324 9A327
NOT
SHOWN
Knob P332606 P332606 P332606 P332606
NOT
SHOWN
Vent Limit Switch Bracket P322074 P322074 P322074 P322074
Thermostat not included with these models.
SINGLE SIDED 1 IN. SIDE CLEARANCE
NATURAL
2509622A 25H9622A 3509622A 35H9622A
PROPANE
2509621A 3509621A
PART NUMBERS FOR THE 250 350 MODELS
