30
• Remove the protective cover by turning anti-clockwise
• Remove the lamp and replace with a new one suitable for high
temperatures (300°C).
• Refit the protective cover.
Oven Lamp
Replacing the Oven Lamps
Let the oven cavity cool down.
Removing the Door Glass
The glass can be removed from the Grill door for cleaning.
Ensure that the cooker is switched off at the mains before replacing the lamp to avoid the
possibility of an electric shock.
Lamp specifications
Voltage: 220 - 240V
Wattage: 15W
Lamp Type: G9
• Ensure the door glass has cooled down.
• Take care when handling parts with glass, knocks, chips, heavy handling and dropping could cause
the glass to shatter.
1. Open the door slightly.
2. The grill door has a vent at the top
that can be removed. Press the clips
on either side of the vent and gently
remove the vent. Be careful the grill
door doesn’t spring closed.
3. Remove the glass, taking care not to
knock or damage it. This can now be
cleaned.
4. The glass has a coating which reflects
heat back into the cavity so its
important that when replacing the
glass you make sure its the correct
way around. Make sure you can see
words ‘THERMAL REFLECTOR’ when
the door is open.
