Wilo T 17.3 P Series User Manual

en Product description
58 WILO SE 2019-10
Asynchronous motor Permanent magnet motor
T20.2 T17.3...-P T20.2...-P
Non-immersed operating mode
S2* S2* S2*
Dry well installation operating mode
S2* S2* S2*
Upper rolling bearings: permanently lubricated,
low-maintenance
• • •
Lower rolling bearings: permanently lubricated,
low-maintenance
• • •
Connection cable sealed as longitudinally wa-
tertight
• • •
! = Required/mandatory, • = Standard, o = Optional, − = Not available
* The operation duration in minutes depends on the motor power, see rating plate.
4.1.3 Seal
Different methods are used for the seal to the fluid and the motor compartment:
ƒ Version "G": two separate mechanical seals
ƒ Version "K": two mechanical seals in a block seal cartridge made of stainless steel
Leakage from the seal is caught in the sealing chamber or leakage chamber:
ƒ The sealing chamber accommodates any possible leakage of the seal on the fluid
side.
This sealing chamber is filled with medicinal white oil ex works.
ƒ The leakage chamber accommodates any possible leakage of the seal on the motor
side.
The leakage chamber is empty ex works.
CAUTION!In the case of motors without an additional leakage chamber, the leak-
age from the seal on the motor side is taken up in the motor!
Overview of gasket and leakage chamber
Asynchronous motor Permanent magnet motor
T20.2 T17.3...-P T20.2...-P
Sealing chamber
• • •
Leakage chamber
• − •
• = Standard, − = Not available
4.1.4 Material
The following materials are used in the standard version:
ƒ Pump housing: grey cast iron
ƒ Impeller: grey cast iron
ƒ Motor housing: grey cast iron
ƒ Seal on the motor side:
– "G" = Carbon/ceramic or SiC/SiC
– "K" = SiC/SiC
ƒ Seal on the fluid side: SiC/SiC
ƒ Static seal: FKM (ASTMD1418) or NBR (nitrile)
The precise details of the materials used are shown in the respective configuration.
4.2 Digital Data Interface
NOTICE
Note the instructions for the Digital Data Interface!
Read the separate instructions for the Digital Data Interface and comply with them.
The Digital Data Interface is a communication module with integrated web server that
has been integrated in the motor. It is accessed and controlled in an Internet browser
using a graphical user interface. The user interface enables easy pump configuration,
control and monitoring. Different sensors may have been installed in the pump for this
purpose. External signal transmitters may also input additional system parameters in
the control. The Digital Data Interface is capable of the following, depending on the
system mode:
ƒ Pump monitoring.
