13 Factory settings For the factory settings, see Tab. 12 below.
Tab. 12: Factory settings
Menu
no.
Designation Factory-configured values
1.0.0.0
Setpoints • Controller:
approx. 60% of n
max
pump
• Δp-c:
approx. 50% of H
max
pump
• Δp-v:
approx. 50% of H
max
pump
2.0.0.0
Control mode Δp-c activated
3.0.0.0
Δp-v gradient Lowest value
2.3.3.0
Pump ON
4.3.1.0
Base-load pump MA
5.1.1.0
Operating mode Main/standby mode
5.1.3.2
Internal/external pump
cycling
Internal
5.1.3.3
Pump cycling time interval 24 h
5.1.4.0
Pump enabled/disabled Enabled
5.1.5.0
SSM Collective fault signal
5.1.6.0
SBM Collective run signal
5.1.7.0
External off Collective external off
5.3.2.0
In1 (value range) 0–10 V active
5.4.1.0
In2 active/inactive OFF
5.4.2.0
In2 (value range) 0-10 V
5.5.0.0
PID parameter See chapter 9.4 “Setting the con-
trol mode” on page 95
5.6.1.0
HV/AC HV
5.6.2.0
Emergency operation speed approx. 60% of n
max
pump
5.6.3.0
Auto reset time 300 s
5.7.1.0
Display orientation Display on original orientation
5.7.2.0
Pressure value correction Active
5.7.6.0
SBM function SBM: Run signal
5.8.1.1
Pump kick active/inactive ON
5.8.1.2
Pump kick interval 24 h
5.8.1.3
Pump kick speed n
min
