se C T i o n 4 � 4 —r e s i s T o r s
35
Wilson Audio Specialties
Tweeter and Mid Range Levels
2.10 ohm Resistor 4.80 ohm Resistor
Tweeter Level
2.40 ohms
(2x 4.80 ohms in parallel)
Midrange Level
1.05 ohms
(2x 2.10 ohms in parallel)
Woofer Crossover
30.0 ohm Barrel Resistor
Resistor Values
Note: These specialized resistors can be ordered from your Authorized Wilson Audio Dealer or on
the Wilson Audio Online Store. Only use Wilson Audio replacement resistors in your Alexia V.
Note: If you notice the sonic qualities of your system degraded or worsen you may have resistors
that are damaged. These resistors don’t always “open up” like fuses and can continue to pass a
signal when damaged. This is most commonly attributed to sudden surges in the system from
blackouts, clipping, or “pops” associated with disconnecting cables without muting the amps.
Please replace the resistors as soon as possible to bring the performance and life back into your
system.
