WARNINGS & PRECAUTIONS
Recommended for indoor use.
Recommended operating temperature is 10-40 °C, 50-104 °F
Keep all liquids away – risk of electrical shock.
NEVER use if SAFETY COVER is missing or loose.
Exposed moving parts could cause serious injury!
Never open Motor housing. Opening voids warranty.
Never insert fi ngers or body parts into motor housing. Cause for bodily harm!
Never service when plugged in.
Extension cords should be carefully chosen and inspected regularly. Replace rather than repair.
Wilson will not be held liable for any damage (direct or indirect) caused by incorrect
installation, poor maintenance, non-approved alterations or improper use. We will also
be not be held of liability for failure to comply with safety standards for accidents, fi re
or for the safety of electrical installations.
This stringing machine is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the machine
by a person responsible for their safety.
Make sure the stringing machine is always turned off before cleaning it or
servicing one of its components. Unplug the power cable from the mains socket.
Never wash the machine using water, a hose or high-pressure cleaning.
Cleaning and maintenance should be done only as detailed in this manual
or at www.wilson.com/baiardo
Assembling the Machine
To assemble the machine, follow all steps listed on the included set-up guide in order.
To acquire a new or missing set-up guide go to www.wilson.com/baiardo to download a copy.
All parts are shown in the set-up guide. Contact your Wilson representative immediately
if any parts are missing.
All tools for assembly are included.
Some steps require two people as noted in the set-up guide.
Use EXTREME caution until fully assembled.
2.1 PARTS
3.1 ASSEMBLING
3
4
1
3
2
5
6
7
10
8
9
12
11
13
14
16 17 1915
21 22
25
25
26
26
23
24
20
18
Description of Parts
Turntable1.
Turntable Brake2.
Turntable Friction On/Off3.
Outer Support Arms4.
Inner Support Arms5.
Puller6.
Motor Housing7.
Touch Screen & Electronics Box8.
Tool Tray9.
Phone Tray10.
Safety Cover11.
Vertical Column12.
Floor Plate13.
Leveling Adjustments14.
Hex Wrench Set15.
Starting Clamp16.
Cutter17.
Awl 18.
Pliers19.
Power cord20.
Clamps21.
Wire Cover22.
Inner Support Pads23.
Decorative Cover24.
Description of Parts
Badminton
Inner Support Arms25.
Badminton Adapters26.
