Parts Listing – Gearbox – Models 8201VS and 8203VS
Ref Part.
No. Number Description Qty
1 5513790 Housing Gearbox 1
2 5513791 Packing 1
3 5783861 Plug 2
4 5783911 Gauge, Oil Level 1
5 5513794 Shaft, Lower Wheel 1
6 5513795 O-Ring (P15) 1
7 5513796 O-ring (P24) 1
8 5513797 Block, Clutch 2
9 5513798 Gear (O) 1
10 5783971 Spacer 1
11 5513800 Cover, Bearing (O) 2
12 5513801 Pulley 1
13 5784121 Bushing 1
14 5784051 Seal, Oil (12x22x7) 1
15 5513804 Rod, Clutch 1
16 5513805 O-Ring (P9) 2
17 5784091 Knob (M10) 1
18 5513807 Gear, Helical (M) 1
Ref Part.
No. Number Description Qty
19 5783951 Shaft, Gear (M) 1
20 5783871 Cover, Oil Seal (30x7) 1
21 5784141 Cover, Bearing (M) 1
22 5783991 Shaft, Gear (I) 1
23 5783881 Seal, Oil (17x40x7) 1
24 5784151 Cover, Bearing (I) 1
25 5513814 Speed Changer, 1
Non-Step (Set)
26 5513815 Belt, Synchronous 1
(V-Type)
27 5513816 V-Belt (A51) 1
28 - - - - - - - - - - - - -
29 - - - - - - - - - - - - -
30 - - - - - - - - - - - - -
31 9100441 Bearing (6200ZZ) 3
32 5783851 Bearing (6203ZZ) 1
33 5783931 Bearing (3206ZZ) 1
Ref Part.
No. Number Description Qty
34 5629151 Bearing (6206ZZ) 1
35 5783961 Key (5x5x18) 1
36 5784011 Key (5x5x40) 1
37 5784031 Key (7x7x20) 1
38 5513824 Pin, Parallel (5x20) 2
39 5784071 Pin, Spring (5x30) 2
40 5783941 Ring, Retaining (R62) 1
41 5784041 Ring, Stop (S30) 3
42 5513828 Bolt, Countersunk Head 3
(M5x10)
43 5784161 Screw, Pan Head (M5x8) 9
44 5513830 Bolt, Pan Head (M6x16) 8
45 5513831 Bolt, Hex Head Socket 1
(M8x12)
46 5513832 Screw, Set (M6x10) 2
47 5513833 Plug, Oil 1
