27
Parts List – Optional Riser Block – All Models
Ref Part.
No. Number Description Qty
1 5784511 Block, Riser 1
2 5784521 Guard, Blade 1
3 5784531 Hook, Bracket 2
4 5784541 Screw, Self Tapping 4
5 5784551 Screw, Hex Head (M16x2x200) 1
6 5784561 Washer (M16) 1
7 5784571 Nut (M16) 1
8 5784581 Post, Guide 1
9 5784591 Guard, Upper Wheel Blade 1
10 5784611 Extender, Blade Guard 1
11 5784621 Bolt, Carriage (M8x15) 1
12 5784631 Washer (M8) 1
13 5782581 Nut, Wing (M8) 1
14 5784641 Blade, Saw (Metal Cutting) 1
5784681 Blade, Saw (Wood Cutting) 1
15 5784651 Pin, Dowel 2
16 5784661 Cord, Extension Power (1-Phase) 1
5784671 Cord, Extension Power (3-Phase) 1
