WMP-17F User’s manual
5
LCD Specifications
Model Name
G170EG01 (V0)
Display Type
17” color TFT LCD
Max. Resolution
1280 x 1024
Contrast Ratio
1000 : 1 (Typ)
Pixel Pitch (mm)
0.264 (per one triad) x 0.264
Luminance (cd/m2)
350 (TYP)
Viewing Angle
170°(H)
160°(V)
Operating Temperature
0°C~ 40°C (32°F~104°F)
Brightness Control
Yes
Cautions:
Continuous displaying fixed pattern may induce image sticking.
It’s recommended to use screen saver or moving content
periodically if fixed pattern is displayed on the screen.
Power Adapter Specifications
Power
Close-frame
MFR
Sinpro
Type
HPU101-105
Input Rating
AC 100 ~ 240 V, 1.2 – 0.5A @ 47 ~ 63 Hz
Output Rating
DC 12V, 8.33A
MTBF
100,000 hrs operation at 25°C
Classification
Power by Class I certified power adapter.
No applied part.
Mode of operation
Continuous operation
System input rating
DC 12V, 8.33A
Mechanical Specifications
Architecture
Close-frame
Front Bezel
PET bezel with resistive touch screen
Color
Medical-white
Mounting / Holder
VESA 75/100mm
Construction
3mm ABS + PC TYPE Plastic housing
Dimension (WxHxD)
420mmx 360mm x 83 mm
Net Weight
6.5kg (w/o power adapter)
Packing Filler
PE
