WMP-17F User’s manual
4
Specifications
[
Hardware Specifications
Display
17” 350 nits SXGA color TFT LCD
CPU Support
LGA1151 package 6
th
generation Intel®
Core i7/i5/Pentium processor (35W max.)
Disk Drive Space
2.5” Hard Disk Drive (SATA III)
Expansion
Two Mini PCIe slot (+3.3V loaded 300mA, total
loaded 1.98W; only for isolated version);
One PCI-E expansion slot (3.3V loaded 2A, total
loaded 6.6W)
Button
Brightness down/Brightness up // Power //
Volume down/Volume up
I/O
Standard version
RS-232 port *1 + RS-232/422/485 port *1
USB 3.0 port *4,
DC-in w/ lock function *1
Gigabit LAN RJ-45 Connectors *2
DP x 1 + DVI x 1
Sound:
Line-in *1
Line-out *1
2W Speaker *2
Optional: PCI or PCI-E slot x 1
Isolated version
RS-232 port *1 + RS-232/422/485 port *1
ISO-RS232 *1 + ISO-RS232/422/485 * 1
USB 3.0 port *4,
ISO USB2.0 * 1
DC-in w/ lock function *1
Gigabit LAN RJ-45 Connectors *2
ISO giga-LAN *1
DP x 1 + DVI x 1
Sound:
Line-in *1
Line-out *1
2W Speaker *2
