If enabled, this requires additional firmware in the
SPI device
BIOS Hotkey Pressed
OEMFLag Bit 1:
Enable/Disable BIOS hotkey press.
MEBx Selection Screen
OEMFLag Bit 2:
Enable/Disable MEBx selection screen.
Hide Un-Configure ME Confirmation Prompt
OEMFlag Bit 6:
Hide Un-Configure ME without password
Confirmation Prompt
Un-Configure ME
OEMFlag Bit 15:
Un-Configure ME without password.
Serial Port Configuration
Serial Port 1 Configuration
Set Parameters of Serial Port 1 (COMA)..
Serial Port 2 Configuration
Set Parameters of Serial Port 2 (COMB).
Serial Port 3 Configuration
Set Parameters of Serial Port 3 (COMC).
Serial Port 4 Configuration
Set Parameters of Serial Port 4 (COMD).
Serial Port 5 Configuration
Set Parameters of Serial Port 5 (COME).
Serial Port 6 Configuration
Set Parameters of Serial Port 6 (COMF).
Hardware Monitor
CPU Fan Control Mode
Select CPU Fan Control Mode
CPU FAN Boundary Hystersis
Boundary hysteresis. (0~15ºC). Segment will change
when the temperature is over the boundary
temperature and below the boundary deducts the
hysteresis temperature.
CPU TEMPERATURE BOUNDARY 1
CPU TEMPERATURE BOUNDARY 1
CPU TEMPERATURE BOUNDARY 2
CPU TEMPERATURE BOUNDARY 2
CPU TEMPERATURE BOUNDARY 3
CPU TEMPERATURE BOUNDARY 3
