Charge Your E-Bike
Before using the electric bike, you must fully charge the battery.
1. Ensure the battery is off, by rotating the key to align with the off icon.
2. Remove the rubber cover on the charging port on the opposite side of the battery from the
key switch.
3. Plug the charger into the battery's charging port. With the battery on or off the bike, place
the charger in a flat, secure place, and connect the DC output plug from the charger to the
charging port on the side of the battery.
4. Plug the charger into a power outlet, charging should initiate and will be indicated by the
LED charge status lights on the charger turning red. Once fully charged, the charging indica-
tor light turning green.Unplug the charger from the wall outlet first and then remove the
charger output plug from the battery charging port.
To reinstall the battery, align the slot at the bottom of the battery and reinsert it into the
frame. Turn the key to the locked position.
lf you want to know the battery level without turn on the bike, long press the button on the
top of the battery to display the current capacity.
Display and Setting
Display Control
TRIP:This figure shows distance data for a single trip. Data is automatically cleared when the
bike is powered off.
Direction Operation
Turn on/off the bike
lncrease pedal assist (PAS) level
Decrease pedal assist (PAS)level
Turn on/off headlight
Press and hold the M button for 3 seconds
Press the + button
Press the - button
Press and hold the + button for 3 seconds after the
display is turned on
km
km/h
TRIP
100％
Speed
Battery Level
0.
00 00.0
1
0
Multifunctional
Display area
