Windsor chariot iExtract CE24 - Scrub Deck and Brush Maintenance

MAINTENANCE-SCRUB DECK
86037880 CHARIOT EXTRACTOR 01/16/07
4-8
4
3
2
7
6
5
1
8
1. Hopper
2. Hopper Retainer Plate
3. Scrub Brush Motor
4. Scrub Deck Lift Actuator
5. Brush Door
6. Motor Assembly Jack Screw
7. Lower Links
8. Brush Pressure Adjustment
