PUMP ASSEMBLY
CLIPPER 86038240
5-
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86002470 22072 1 COUPLING, 1/4 ANCHOR W/1" HEX
2 86002480 22090 2 CONNECTOR, 1/8FPT X 1/4 TUBEQC
3 86003470 31072 1 ELBOW, SWIVEL, 1/4MPTX1/4TUBE
4 86003490 31074 1 ELBOW, SWIVEL, 3/8MPTX3/8TUBEQC
5 86004570 44067 2 JET BODY, MINI PROMAX BODY
6 86004580 44068 2 JET, MINI PROMAX 9504
7 86005640 57030 2 NUT, 10-32 HEX NYLOCK
8 86026390 65201 1 PUMP ASM, 115V 100 PSI W/CONN 1000167303
9 86250140 66288 2 PLUG, 9/16 OD BLK NYLON
10 86274410 70195 2 SCR, 10-32 X 1.25 PPHMS
11 86273750 70011 2 SCR, 1/4-20 X 5/8 HHCS SS
12 86003640 34355 1 FITTING, 1/4 TUBE,"Y", QC
13 86008360 78419 1 TEE, 3/8 MPT X 3/8 TUBE, QC
14 86026940 84160 1 VALVE ASM, SOLENOID CLP FAMILY
15 86010810 87191 2 WASHER, 1/4"IDX1.0OD. FLAT SS
16 86010650 87018 4 WASHER, #10 X 9/16 OD
17 86010820 87192 2 WASHER, 7/16 X 3/4 X .19RUBBER
18 86005590 56014 1 NIPPLE, 1/4 CLOSE
19 86005580 56012 1 NIPPLE, 1/4 FPT QD
20 86003500 31076 2 ELBOW, 1/4 MPT X 3/8 TUBE, QC
21 86274290 70162 2 SCR, 10-32 X 3/8 PPHMS SS
22 - - OPEN
23 86267400 880278 1 WIRE, 22" GRN/18 76011 X 76011
24 86281890 39529 1 HOSE, 3/8 URETHANE X 29"
25 86004350 39530 1 HOSE, 3/8 NYLON X 6"
26 86281900 39531 3 HOSE, 1/4 URETHANE X 6"
27 86253020 73963 1 SCREEN, INTAKE
28 86197400 31022 1 ELBOW, 1/8NPT STREET
29 86004400 39591 1 HOSE, 3/8 ID NYL11 YLW X 29”
To Next Page
