SOLUTION TANK ASSEMBLY
CLIPPER 86038240
5-1
2
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86233140 20041 2 CLAMP, 2.0" WORM GEAR
2 86233150 20042 1 CLAMP, 3/8 HOSE (D-SLOT)
3 86003080 27809 1 COVER, VAC MOTOR
4 86003090 27810 1 COVER, BELT
5 86235500 31081 1 ELBOW, 3/8 MPT X 3/8 TUBE, PLASTIC
6 86003790 35175 2 GASKET, TANK TO VAC COVER
7 86003920 35231 2 GASKET, VAC COVER (CLP FAMILY)
8 86281880 39526 1 HOSE,1/2 CLEAR X 12
9 86240100 39536 1 HOSE, 1.5 BLK VAC X 5.0
10 86004340 39528 REF HOSE ASM, 1.5 BLK VAC X 15.5
11 86240980 41348 1 HOUSING, VAC MOTOR
12 86026880 53789 1 VAC MOTOR ASM, CLP FAMILY
12A 86135340 14258 BRUSH SET, 120V 5.7 VAC, AMETEK
* SERVICE
ONLY
12B 86135320 140687 BRUSH SET, 120V VAC, WINDSOR
* SERVICE
ONLY
13 86275690 70525 6 SCR, #10 X 1.0 PPHST TYPE B
14 86032280 75261 1 TANK, CLP SOLUTION
15 86259070 85038 1 VENT, COOLING AIR LARGE
16 86010650 87018 8 WASHER, #10 X 9/16 OD
17 86007970 73864 1 STRAINER, 3/8 IN. NPT 60 MESH
18 86010630 87013 3 WASHER, 1/4 ID X 5/8 OD SS
19 86006580 70085 3 SCR, 1/4-20 X 1/2 PPHMS SS DL
20 86233260 20092 1 CLAMP, 3.5" WORM GEAR
21 86003950 35236 1 GASKET, TANK, L-F
22 86003960 35237 1 GASKET, TANK, L-R
23 86003970 35238 1 GASKET, TANK, RH
24 86197940 40027 1 HOSEBARB, 3/8MPTX1/2 90D DL
25 86006600 70114 2 SCR, #10 X 3/4 PPHST TYPE B
26 86260690 02130 1 HOSE ASSY- FILL HOSE
27 86002870 27417 1 CORD, 99807 1/8 X 12"
28 86197920 40023 1 HOSEBARB, 1/2MPT X 3/8 DL
29 86234790 27827 1 COVER, CLP SOLUTION
30 86246060 51321 1 LANYARD, .06 X 2.88
31 86026680 75278 1 TANK ASM, SOLUTION CLP12
*ITEMS
INCLUDED
32 86233090 20016 1 CLAMP 1/4 ID HOSE
