BRUSH ASSEMBLY PARTS LIST
CMD20 86038150 04/02/07
29
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86227630 03100 1 AXLE, .5 X 19.5 X 1/4-20
2 86227640 03101 1 AXLE, .50 X 4.34 W/FLATS
3 86000900 09019 5 BEARING, 1.125 OD X .500 ID X .375
4 86000920 09055 2 BEARING, FLANGE
5 86229420 11043 1 BELT, TIMING .375P 16.5 PL .5W
6 86001120 12023 1 BRUSH, 18L X 4.5 OD
7 86234540 22087 2 COUPLER, 1/2 JAW
8 86234550 22088 1 COUPLER, SPIDER
9 86238590 36188 1 GUARD, SPLASH
10 86241210 42069 2 IDLER, BRUSH QUICK-CHANGE END
11 86247070 53093 1 MOTOR, 115V 1/3 HP W/O T/O
12 86005640 57030 11 NUT. 10-32 HEX NYLOCK
13 86005680 57047 1 NUT, 1/4-20 HEX NYLOCK
14 86005750 57113 4 NUT, 5/16-18 HEX NYLOCK
15 86081460 62747 1 PLATE, BELT ADJUSTMENT
16 86250660 64094 1 PULLEY, TIMING 2.029 PD X .375P
17 86250670 64095 1 PULLEY, TIMING .375 10T .51D
18 86272760 67093 2 RING, 1.13 RETAINING HO
19 86086190 67395 1 RETAINER, SPLASH GUARD
20 86273750 70011 2 SCR, 1/4-20 X 5/8 HHCS SS
21 86273800 70017 1 SCR, 1/4-20 X 2.50 HHCS SS
22 86006610 70124 3 SCR, 1/4-20 X 1/4 SSSCU
23 86274270 70160 11 SCR, 10-32 X 5/8 PPHMS
24 86006750 70302 4 SCR, 5/16-18 X 1.00 HHCS GR5
25 86275380 70448 4 SCR, 6-32 X 1/2 PFHMS PLTD
26 86278850 80613 2 WASHER, .506 X .94 NYL
27 86010660 87025 2 WASHER, 1/4 EXT STAR SS
28 86010670 87029 8 WASHER, 5/16 X 3/4 SS
29 86279580 87183 2 WASHER, 1/2 X 1.00 NYL
30 86259690 89051 2 WHEEL, CMD VAC SHOE
31 86090400 89134 1 WELDMENT, BRUSH HOUSING
32 86078630 140277 1 BRKT, RUSH HOUSING END CAP
SERVICE PARTS LIST
PART NO. PRV NO. DESCRIPTION PARTS INCLUDED
86025320 42072 IDLER, ASSEMBLY, BRUSH CMD20
86000900 – PRV NO. 09019 (1),
86241210 – PRV NO. 42069 (1),
86272760 – PRV NO. 67093 (1)
86026130 53635 MOTOR ASSEMBLY, BRUSH CMD20
86247070 – PRV NO. 53093 (1)
W/MOLEX CONN.
86026220 64097 PULLEY ASSEMBLY, BRUSH CMD20
86272760 – PRV NO. 67093 (1),
86275380 – PRV NO. 70448 (4),
86000900 – PRV NO. 09019 (2),
86241210 – PRV NO. 42069 (1),
86250670 – PRV NO. 64095 (1)
