SOLENOID AND MANIFOLD ASSEMBLIES PARTS LIST
CMD20 86038150 04/02/07
31
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86233150 20042 3 CLAMP, 3/8 WORM GEAR
2 86063740 27775 1 COVER, BRUSH MOTOR
3 86197360 31016 1 ELBOW, 1/4 NPT, STREET
4 86197550 40014 1 HOSEBARB, 1/4 MPT 3/8
5 86197600 40033 2 HOSEBARB, 1/4 MPT X 3/8H 90 DEG
6 86004570 44067 2 JET, MINI PROMAX BODY
7 86004580 44068 2 JET, MINI PROMAX 9504
8 86245830 50947 1 LABEL, ADJ INSTRUCTION
9 86005540 54165 1 MANIFOLD, CMD20
10 86005580 56012 1 NIPPLE, 1/4 FPT QD
11 86197670 56023 1 NIPPLE, 1/4 X 1.5
12 86270860 57028 4 NUT, 10-24 TINNERMAN
13 86005640 57030 1 NUT, 10-32 HEX NYLOCK
14 86006180 66095 2 PLUG, 1/8 MPT HEX BRASS
15 86006600 70114 2 SCR, #10 X 3/4 PHST TYPE B
16 86274270 70160 1 SCR, 10-32 X 5/8 PPHMS
17 86274290 70162 2 SCR, 10-32 X 3/8 PPHMS SS
18 86006870 70406 4 SCR, #10 X 3/8 PHSM TYPE B BLK
19 86197760 78308 1 TEE, 1/4 STREET
20 86258870 84168 1 VALVE, 120V 110 PSI SOLENOID
21 86010640 87016 3 WASHER, #10 EXT STAR SS
SERVICE PARTS
PART NO. PRV NO. DESCRIPTION PARTS INCLUDED
86026480 84157 SOLENOID ASSEMBLY 86258870 – PRV NO. 84168 (1) W/MOLEX CONN.
86026040 54168 MANIFOLD ASSEMBLY, CMD20
86005540 – PRV NO. 54165 (1),
86004570 – PRV NO. 44067 (2),
86004580 – PRV NO. 44068 (2),
86006180 – PRV NO. 66095 (2),
86197600 – PRV NO. 40033 (1)
