Windsor Saber Compact SC20 - Traction Model Controls

CONTROLS - TRACTION
SABER (SC) 86038350 01/29/07
3-7
1. Solution Control Knob
2. Brush Switch
3. Brush Lift Lever
4. Vacuum Switch
5. Squeegee Lift Lever
6. Key Switch
7. Propel Buttons (Normally Forward)
8. Reverse Propel Button
9. Speed Control Knob
10. Battery Charge Level Indicator
11. Emergency Shut Off Switch (Optional)
12. Hour Meter (Optional)
13. Circuit Breakers
