TECHNICAL SPECIFICATIONS
SABER (SC) 86038350 01/29/07
3-1
ITEM DIMENSION/CAPACITY
Nominal power – non-traction model 1100 W
Nominal power – traction model 1200 W
Rated Voltage 24VDC
Rated Amperage – non-traction model 45 Amps
Rated Amperage – traction model 50 Amps
Batteries 2 x 12 Volt 105-130-195 AH @
20hr rate
Scrub Brush Motor .75 hp (0.56 kW)
Vacuum Motor .75 hp (0.56 Kw)
Propelling Motor – traction model .38 hp (0.28 Kw)
Mass (GVW) – non-traction model 543 lbs. (246.5 kg)
Mass (GVW) – traction model 556 lbs. (252.4 kg)
Weight empty without batteries – non-traction model 213 lbs. (96.1 kg)
Weight empty without batteries – traction model 232 lbs. (105.3 kg)
Solution Control – non-traction model Gravity feed, fully variable
Solution Control – traction model Gravity feed, fully variable with
automatic shut-off in neutral
Solution tank capacity 13 gal. (50 l)
Recovery tank capacity 16 gal. (60 l)
Scrub brush diameter 20 in (51 cm)
Scrub brush pressure – non-traction model 50 lbs. (23 kg)
Scrub brush pressure – traction model 100 lbs. (45 kg)
Scrub brush speed 200 rpm
Tires – non-traction model 2 x 8 in (20 cm) thermoplastic
elastomer non-marking
Tires – traction model 2 x 8 in (20 cm) foam filled non-
marking
Casters 3.5 x 1.25 in (9 cm) polyurethane
solid non-marking
Foundation Pressure – non-traction model 105 lbs./in
2
( 725 kPa)
Foundation Pressure – traction model 46 lbs./in
2
( 315 kPa)
Maximum Speed – traction model 2.75 miles/hour (4.5 km/hour)
Coverage 9500 ft
2
/hour at 2 mph with
2 in. overlap
Frame Construction Steel with epoxy powdercoat
finish.
Minimum aisle u-turn width 45 in. ( 114.3 cm)
Maximum rated climb and descent angle with empty tanks 2%
Maximum rated climb and descent angle with full tanks 2%
