Windsor SCC172 Instructions

SQUEEGEE
86221970 17” SCRUBBER 09/17/10
5-22
REF PART NO. PRV NO. QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86223740
70872 2 SCR, 1/4-20 X .59 PPHMS SS C
2
86225450
78936 1 TUBE, 17 IN. TRANSITION
3
86332620
- 1 GASKET, SUCTION, SQG TRANS
4
86219690
48080 2 KNOB, 1.5 OD X 5/16-18
5
86215800
140883 1 BRKT, SQUEEGEE MOUNT
6
86219730
48112 10 KNOB, SQUEEGEE RETAINER
7
86224950
730366 1 STRAP, SQUEEGEE BLADE, REAR
8A
86215360
730372 1 BLADE, SQUEEGEE, REAR
8B
86007370
730058 1 BLADE, RED REAR SOFT DURO 40 OPTIONAL
8C
86007260
730003 - BLADE, BLU, RIB FRT/REAR URETHANE OPTIONAL
8D
86007610
730227 - BLADE, RED, REAR MEDIUM DURO 60 OPTIONAL
9
86224240
70870 2 SHOULDER BLT, .305 OD X 1.77 SS C
10
86225790
87504 4 WASHER, 5/16 X .63 SS
11
86011020
89202 2 WHEEL, 3” DIA CUSHION RUBBER
12
86001350
140390 2 BUSHING, SPANNER .435 X 1.10
13
86334640
- 1 PLATE, TOP, CAST SQG
14
86222300
57309 6 NUT, 5/16-18 JAM SS
15
86332670
- 2 SQUEEGEE, END INSERT 17 IN
16
86223750
70873 2 SCR, 5/16-18 X 1.77 BHSMS SS
17
86223760
70874 2 SCR, 5/16-18 X 2.17 BHSMS SS
18A
86215350
730371 1 BLADE, SQUEEGEE FRONT
18B
86007360
730057 1 BLADE, RED FRONT 5 SLOT DURO 40 OPTIONAL
19
86087870
730002 1 STRAP, FRONT AND REAR STANDARD
20
86010880
89058 2 WHEEL, 1.5 OD X .31 ID X .75 W GRY
21
86225780
87503 4 WASHER, 5-16 X .55 SS
22
86008660
80605 2 COTTER, 5/16” RING
23
86279650
87222 2 WASHER, SEAL 5/16 X 3/4 OD SS
24
86215810
140884 2 BRKT, SQG WHEEL
25
86222590
66876 2 PIN, CLEVIS 5/16 1.469 C
26
86222290
57308 2 NUT, 5/16-18 HEX NYLOCK SS
27
86332630
- 1 GASKET, LOWER, 17" SQG
28
86332650
- 1 SQUEEGEE, CENTER INSERT, 17IN
29
86276610
70697 2 SCR, 1/4-20 X 1.25 PPHMS SS
30 86224870 730384 1 SQUEEGEE, 17 INCH CAST
*
* COMPLETE ASSEMBLY, ITEM 5 NOT INCLUDED
