WIRING-MAIN HARNESS-SCHC172
86221970 17” SCRUBBER 04/17/09
5-36
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86218890 880448 1 HARNESS, SCRUBBER 172
2 86261230 29242 1 DIODE ASM, 76031 X 76042
3 86261240 29243 1 DIODE ASM, 76031 X 76031
4 86261340 67457 1 RESISTOR ASM, 2.7K OHM 1 WATT
5 86268570 88401 1 WIRE, 3” BLK/14 76029 X 76029
6 86267420 880283 2 WIRE, 3.5 BLK/18 76011 X 76040
7 86267410 880282 2 WIRE, 6” RED/14 76010 X 76029
8 86267620 880306 1 WIRE, 5.5 BLK/14 76001 X 76029
9 86268380 88286 1 WIRE, 4” RED/14 76029 X 76029
10 86267360 880271 1 WIRE, 14” BLK/18 76011 X 76040
11 86226170 880447 1 WIRE, 5” RED/18 76031 X 76047
12 86226190 880450 1 WIRE, 11.5” RED/14 76001 X 76029
13 86268030 880456 2 WIRE, 14” RED/10 76081 X 76064
14 86226210 880457 1 WIRE, 9” RED/12 76064 X 76076
15 86014120 - 1 WIRE, 6” RED/10 76064 X 76064
