Setting up the Rear Cab MountPage 3
Setting up the Rear Cab Mount
Parts
Recommended Tools and Materials (Not Provided)
1/4″ or 3/8″ drive with 1/2″ socket
1/4″ or 3/8″ ratchet to match socket
1/2″ wrench
7/16″ wrench
9″ or 12″ torpedo level
Phillips screwdriver
Side cutters
Wire connector crimpers
Wire strippers
5/16″ drive
1/8” Allen wrench
3/8” wrench
The pivot plate and rear cab mount base are heavy. Exercise caution when lifting and installing these parts.
Recommended tools and materials may not apply in all installations. Consult the vehicle manufacturer to
determine appropriate tools and materials for a secure installation, and adhere to any vehicle manufacturer’s
specifications. Failure to comply with vehicle manufacturer’s specifications may lead to property damage,
personal injury, and/or death.
#10-32 Cap Screw (3)
#10-32 Nut (3)
WiFi Mount
Spacer (3)
Cable Entry Plate
Mounting Screw (8)
1/4″-20 Bolt (4)
Rear Cab
Mount Base
Pivot Plate
5/16” Nyloc Nut (4)
5/16” Screw (4)
Wall Plate
Shorter Cable Tie (2)
Cable Clamp (4)
Power Switch
Wall plate Screw (4)
Terminal Insulator (2)
Barrel Crimp Splice
1/4″-20 Lock Washer (4)
Longer Cable Tie (4)
Dome screw (6)
