RoadTrip T4 In-Motion Antenna 4
DISH
®
Receiver Setup
Satellite “In” port
Back of 211z receiver shown
4) Select option 1; Point Dish.
1) Before starting, disconnect the coax cable from the Satellite
In port on the back of the receiver.
2) Press Menu on your remote. Select option 6; System Setup.
3) Select option 1; Installation.
9) Select Test again to install the SW64 switch. This SW64
switch is a DISH receiver setting, not a physical part.
6) Select Test.
It will go through a number of steps, then return to the
screen shown here with previous information cleared.
If at any point it asks you to save, select Save or Yes.
7) Reconnect the coaxial cable to the “Sat In” port on
back of receiver. Power on the antenna. Allow it 8 –10
minutes to acquire satellites.
8) Check that there are no checkmarks by SuperDISH or
Alternate. If setting up a DISH 311, 301, or 500 series
receiver, in some cases you may need to check the
boxes next to Superdish and Alternate before running
the Check Switch test.
5) Select Check Switch.
When you see the SW64 as the installed switch,
the antenna is ready for use.
If using two DISH
®
receivers with the RoadTrip
®
T4
antenna, both receivers must be configured off of
the primary port by following the steps below.
Receiver setup instructions are accurate at time of printing
and may change without notice. Call Winegard tech line for
assistance: 1-800-788-4417.
TIP
Check out online receiver setup guides for
your antenna at www.winegard.com/support.
For more information on receiver compatibility and
programming, visit www.winegard.com/receivers.
Do not proceed to Step 8 until the antenna has
been completely silent for at least one minute.
