13 Technical specifications
Battery Approved CR 2032-1HFE 3 V
lithium cell
Operating temperature
Min. +5 °C
Max. +55 °C
Storage temperature
Min. -25 °C
Max. +70 °C
IP protection rating IP50
Dimensions
Basic length
Outside (A) 30.7 mm
Inside (B) 32.4 mm
Extensions On both sides, increments of
5 mm
Total length, maximum 180 mm
Cam positions in key with-
drawal position
8
Battery Contained in the battery
replacement set:
Ä
Chapter 11 “Spare parts
and accessories” on page 139
Temperature at installation
location
Min. +5 °C
Max. +55 °C
IP protection rating IP54
VdS environmental class 2
Active key/Masterkey
Cylinder type 01 and type 05
Technical specifications
23.05.2018 blueCompact Electronics locking system 143
