12-7
SECTION 12 –
MISCELLANEOUS
If the window will not open after three or more
full turns of the knob, the glass may be stuck to
the sealing gasket. Go to the outside of the coach
and gently free the glass with your fingers. A
periodic light dusting of talcum powder on the
gasket should prevent this from recurring.
Horizontal Slider Windows
Swing the latch handle straight out or up
(depending on the style of window). Grasp the
sliding window edge frame and slide the window
to the side. Be sure the latch is open before trying
to slide the window closed.
Vertical Slider Windows
Vertical windows have spring-loaded catches
on both sides of the window that pop out to hold
the window in its fully raised position. Press the
catches outward toward the frames while
lowering the window.
Push-Out Windows (Optional)
-If Equipped
The bedroom and lounge windows are secured
by four safety latches at the sides and bottoms of
each window.
To open window, release all four window
latches and push open.
1. Side Latches (2) - Pull down toward bottom of
window frame.
2. Bottom Latches (2) - Pull toward the left-hand
side of the window frame.
3. Push window open.
Propping the Windows Open
The bedroom and lounge windows are
featured with prop rods on each side of the
window. These rods have three notches to prop
your windows open at. Push window open slowly
and stop at the preferred notch setting.
Vertical Window Catches
-Typical View
View of interior left-hand side of window
-Typical View
Side
Latch
Bottom
Latch
View of interior right-hand side of window
-Typical View
Side
Latch
Bottom
Latch
