7-19
SECTION 7 –
PLUMBING
WATER SYSTEM DRAIN VALVE LOCATIONS
Model System Drain Valve Locations
25T Waterlines
• Two (2) drain valves in the water service center and two (2)
drain valves located through an access hole beneath the bed.
Also, place the tip of your finger inside the city water
connection and gently press the backflow valve (small
“button” in center of connector) to drain any water left in the
city waterline.
Water Tank
• One (1) valve located in the water service center.
Water Heater
• Drain plug on outside of coach behind service door. Use
socket to remove drain plug.
Water Heater
Bypass Valve
• One (1) valve in rear driver side compartment (located
beneath bed). Remove panel to access.
Winterization
(Antifreeze) Valve
• One (1) valve and antifreeze siphon tube in rear driver side
compartment (located beneath bed). Remove panel to access.
