10
Dimension (axial version) Unit TR50 TR60 TR80 TR100 TR125 TR150
A mm 1130 1735 1735 1735 1735 1735
B mm 670 630 630 800 970 1130
C mm 700 845 845 845 845 845
D mm 120 120 120 120 140 140
E mm 760 1335 1335 1335 1335 1335
F mm 763 1050 1050 1050 1050 1050
G mm 550 603 603 768 938 1103
H mm 250 580 580 580 580 580
I mm 225 123 123 123 123 123
K mm 140 225 225 225 225 225
M mm Ø100 Ø130 Ø130 Ø130 Ø130 Ø130
N mm Ø100 Ø130 Ø130 Ø130 Ø130 Ø130
O mm 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
P mm 600 570 570 740 910 1070
R mm 195 220 220 220 220 220
S mm 95 143 143 143 143 143
T mm 165 127 127 127 127 127
U mm 80 88 88 88 88 88
Suspension screw type - M10 M10 M10 M10 M10 M10
Weight kg 100 135 150 200 230 260
4 Installation
4.1 Preparation
Before installation, please use the data badge to check:
• if the heater is in accordance with the order;
• if the heater is suitable for the local present
provisions (gas type, gas pressure, electrical supply
etc.)
Before leaving the factory, the air heater has been tested
for safety and has been set to the operating settings. It has
been configured for the type of gas that is stated on the
data badge. Should there be any doubt about the settings
that apply to your situation, please contact your supplier.
4.1.1 Standards
NOTICE The installation must comply with all applicable
local and national standards.
NOTICE The air heater must be installed in accordance
with the relevant requirements of the Gas Safety
regulations, Electrical installation regulations and or other
local regulations that may apply.
For United Kingdom only:
NOTICE The air heater must be installed in accordance
with the relevant requirements of the Gas Safety
regulations, Electrical installation regulations and or other
local regulations that may apply (e.g. The Institute of Gas
Engineers IGE UP-1 and 2, BS6230, BS5440 building
regulations and the IIE regulations that incorporate the gas
safety regulations).
4.2 Positioning the air heater
Keep the following requirements in mind when choosing a
location to install your air heater:
WARNING! Never install an air heater close to flammable
materials.
• Keep sucient distance between the heater and
any obstructions. This is both for safety reasons
and to allow access for service and maintenance
(figure 3).
• Make sure the air flow to and from the heater is
free from obstacles at least 5 metres in front of the
heater. Also make sure the air intake is free from
obstacles.
