Winterwarm TR10 - Page 30

30
No. Description TR10 TR15 TR20 TR24 TR28 TR40 TR50
1 Burner IB3200 IB3200 IB3200 IB3200 IB3200 IB3200 IB3200
2 Ignition electrode GA3400 GA3400 GA3400 GA3400 GA3400 GA3400 GA3400
3 Ignition cable IY3949 IY3949 IY3949 IY3949 IY3949 IY3949 IY3949
4 Ionisation electrode GA3402 GA3402 GA3402 GA3402 GA3402 GA3402 GA3402
5 Combustion fan GA4500 GA4500 GA4500 GA4500 GA4500 GA4514 GA4514
6 Gas valve GA3394 GA3394 GA3394 GA3394 GA3394 GA3394 GA3394
7 System fan IB4816 IB4816 IB4816 IX4201 IX4201 IX4203 IH4206
8 Burner control unit
(EBM966)
GY5901 GY5901 GY5901 GY5901 GY5901 GY5901 GY5901
9 Pressure switch IB3901 IB3900 IB3911 IB3900 IB3901 IB3902 IB3902
10 Temperature sensor (heat
exchanger)
GY3934 GY3934 GY3934 GY3934 GY3934 GY3934 GY3934
11 Gasket set (TR) GA6712 GA6712 GA6712 GA6712 GA6712 GA6714 GA6714
15 Display board GY5902 GY5902 GY5902 GY5902 GY5902 GY5902 GY5902
24 Delta-T sensor GY3931 GY3931 GY3931 GY3931 GY3931 GY3931 GY3931
25 Rectifier block GY3921 GY3921 GY3921 GY3921 GY3921 GY3921 GY3921
26 Fan relay - - - - - - -
30 Flame insert (1 pc.) GA6500 GA6500 GA6500 GA6500 GA6500 GA6500 GA6500
No. Description TR60 TR80 TR100 TR125 TR150
1 Burner IB3204 IB3204 IB3204 IB3204 IB3204
2 Ignition electrode GA3400 GA3400 GA3400 GA3400 GA3400
3 Ignition cable IY3949 IY3949 IY3949 IY3949 IY3949
4 Ionisation electrode GA3402 GA3402 GA3402 GA3402 GA3402
5 Combustion fan GA4516 GA4516 GA4517 GA4517 GA4517
6 Gas valve GA3314 GA3314 GA3314 GA3314 GA3319
7 System fan IX4201 IX4203 IX4206 IX4207 IX4207
8 Burner control unit
(EBM966)
GY5901 GY5901 GY5901 GY5901 GY5901
9 Pressure switch IB3904 IB3904 GA3968 GA3966 GA3964
10 Temperature sensor (heat
exchanger)
GY3934 GY3934 GY3934 GY3934 GY3934
11 Gasket set GA6716 GA6716 GA6716 GA6716 GA6716
15 Display board GY5902 GY5902 GY5902 GY5902 GY5902
24 Delta-T sensor GY3931 GY3931 GY3931 GY3931 GY3931
25 Rectifier block GY3921 GY3921 GY3921 GY3921 -
26 Fan relay - - IK5200 IK5200 IK5200
30 Flame insert (1 pc.) GA6501 GA6501 GA6501 GA6501 GA6501
