Wiselazer X5 - Projection Distance and Function Overview; Projection Distance and Size Guide; Projector Exterior and Component Identification; Projector Connectivity and Ports

03
The recommended projection screen is around 100 inches with a distance of around 10.04ft.
It is recommended to use the projector in dark and low light environments.
40”
70”
100”
120”
150”
(16:9)
4.31ft
(1.32m)
7.25ft
(2.21m)
10.04ft
(3.06m)
11.93ft
(3.64m)
14.75ft
(4.49m)
3.PROJECTION DISTANCE & SIZE
Air Inlet
Focus Knob
Inch Nut×4(M5) Rear Cover
Rear
Cover
Adjustable
Tilt Foot
Rubber Gasket
Infrared Receiver
Lens
Power Button
Keystone
Correction
Left
Volume +
Volume -
Play/Pause
HDMI Input
Source
Up
Right
Back
Menu
Fast Reverse
Fast Forward
Mute
Down
4.FUNCTION OVERVIEW
Infrared
Receiver
Speaker
Audio
Out
Power
Indicator
Power
Iuput USB
HDMI
Open the cover on the bottom and take
out the dust filter for cleaning
Dust Filter
(These nuts are under the rubber gaskets)
Power
Button
OK Back Left Right Up Down Menu Keystone
Correction
