10
HOPPER OPENING
Apply adhesive side of insulation rope to the top edge of the hopper opening, and then fold the rope over
the hopper opening edges.
FEED TUBE AND TUBE LID
Apply adhesive side of insulation rope to the top edge of the feed tube opening, and then fold the rope over
the feed tube opening edges. Apply adhesive side of insulation rope to open side of feed tube lid. Overlap
the rope on the open edge of the lid 1/8”, and leave a 1/4” of space on each end of the rope.
FRONT AND BACK SIDE OF HOPPER FEED TUBE
Apply silicone around all four edges Fill the entire void
SEAL INSTRUCTIONS
