WiseWay GW1949 - Assembly Procedures; Installing Temperature Gauge and Damper Slide; Installing Burn Tubes and Ash Tray

9
Use a pair of needle nose pliers to install the
temperature gauge.
Insert the damper slide into place; it will only
fi t one way.
Screw on damper slide handle by turning
clockwise.
Install primary burn tube, secondary burn plate, and ash tray.
Damper Slide
Damper Slide Handle
Primary Burn Tube
Secondary Burn Plate
Ash Tray
ASSEMBLY
