MENU TREE
*
1
Depending on the customization
*
2
Only with a Mode “mono”
MAIN
Ch-Gr
CH: 00 ÷ 59 GR: 00 ÷ 39
Frequency: 470÷800 MHz
Group name
Mode
ENR-Wisy Stereo / EVO Stereo / ENC-Wisy Stereo / SR Stereo /
ENR-Wisy / ENC-Wisy / EVO / SEN / SEN -d0 / COM-Wisy 25K /
COM-Wisy 20K / COM-Wisy 12K5 / MAX / USER 1..7 / *
1
TX on air at
startup
Yes / No
TX Power 10 / 20 / 50 / 100 / 200 mW
Audio source
Input Analog / digital
Max audio
level
-6 ÷ 18 dBµ
Audio gain
left
-20 ÷ 24 dBµ
Audio gain
right
-20 ÷ 24 dBµ
AF level
meter
input / modulation
Mono config *
2
mono/mono-R/mono-L
Equalizer
Bass
G: -12 ÷ 12 dB
Fr: 40 / 80 / 160 Hz
Mid
G: -12 ÷ 12 dB
Fr: 1.5 / 2.2 / 2.8 KHz
Q: 0.7 / 1.0 / 2.0
Treble
G: -12 ÷ 12 dB
Fr: 5.0 / 0.7 / 10.0 KHz
SAVE/NEXT/ EXIT
Options
Name
DISPLAY
brightness
0 ÷ 15
DISPLAY
timeout
5 ÷ 120
Info…
IP
Serial
Option
Range
Power profile
Temperatures
RF amplifier
RF generator
Micro
Power supply
FW ver.
Boot ver.
App FW ver.
DSP FW ver.
Alarms
