rev.02
MTK952 User Manual
8
To access the configuration menu of the transmitter is necessary to press the rotary knob (at the
right of the display①).
To activate one of the items in the menu, press the corresponding button to the right of the
display (see picture hereafter②).
②
①
MODE
Select for edit
Name
Mono/stereo
Compander
HP filter
Flat / 20 /40 / 60 / 80 / 120
/ 170 / 250 / 300 HZ
LP filter
3 / 4 / 12 / 15 / 20 KHz
Pre-emphasis
Bypass / 10-750 µs
FM peak deviation
2 ÷ 100 KHz
TSQ frequency
30 ÷ 260 KHZ
28 ÷ 34 KHz
TSQ deviation
OFF / 100 Hz ÷ 5 KHz
