HWT9053-RS485 | manual v0707 | http://wiki.wit-motion.com/english

- 19 -

2.4 Configuration

2.4.1 Baud Rate

The module supports multiple baud rates, and the default baud rate is 9600.

To set the baud rate of the module, you need to select the baud rate to be

changed in the communication rate drop-down box in the configuration bar

based on the correct connection between the software and the module.

Note: After the change, the module will no longer output data at the original

baud rate. The data will be output only when the baud rate that has been

changed is selected on the PC software again.

2.4.2 Data Recording

Method are as follows:

Step 1: Click “Record” and “Begin”

Step 2: Click “Stop”

Step 3: Extract the data as “txt” file
