WLINK WL-R320 Series User Manual

WL-R320 Series Router User Manual
10
3 Router Configuration
WL-R320 Series routers support GUI. This chapter introduce GUI configuration via Ethernet port, if
need CLI configuration guide, please contact our technical support department by email:
support@wlink-tech.com.
3.1 Local Configure
The router supports to be configured by local Ethernet port, you could specify a static IP or set as DHCP.
The default IP address is 192.168.8.1，subnet mask is 255.255.255.0, please refer to following.
Step 1 Click “start > control panel”, find “Network Connections” icon and double click it to enter, select
“Local Area Connection” corresponding to the network card on this page. Refer to the figure
below.
Figure 2-1 Network Connection
Step 2 Obtain a IP address automatically or set up IP address,192.168.8.xxx(XXX can be any number
between 2～254)
Step 3 Run an Internet Explorer and visit “http://192.168.8.1/”, to enter identify page.
The default username is admin and password is admin168. User should modify the login
password.

WLINK WL-R320 Series Specifications

General

Brand	WLINK
Model	WL-R320 Series
Category	Network Router
Language	English
