WMF 5000S - 4.13 Usb; Load Recipes; Load Cup Symbols; Save Recipes

54
User Manual WMF5000 S
Software | USB
4.13 USB
Data exchange is possible via the USB connection.
Aslong as the USB stick is inserted, the functions will
be active.
The USB connection is at the top left on the back side
of the operating panel, behind acover.
The cover must always be closed and latched when the
coffee machine is in operation.
Load recipes
Saved recipes are loaded here.
Load cup symbols
Save recipes
Export recipes to USB.
Export counters
Counters are exported to aCSV file here.
HACCP export
The cleaning cycles performed are recorded and are
exported here as evidence for HACCP.
DS_03_13_00_01
Load recipes
DS_03_13_00_02
Load cup symbols
DS_03_13_00_03
Save recipes
DS_03_13_00_04
Export counters
DS_03_13_00_05
HACCP export
