Service 22
 Power stage (on CPU-power board)
 10-pole plug 30 V outputs for Grinders, brewer drives, cup storage heater
 96-pole plug 5 V / 24 V inputs and outputs for valves, flow meter, microswitches, etc.
Note:
All outputs, with the exception of the brewer drive, are short circuit protected
The outputs for the brewer drive are rated for lock-up, that is, they can withstand high currents for a longer period of time, but will be destroyed by a
short circuit.
 Side boards – for hot water and auto steam buttons
Below is an illustration of the listed components
