7. THE LUBRICATION SYSTEM
The lubrication of the spindle and the ball bearings are safety-guarded by
the hyperthermia grease lubricant.
For the bed track and the surface of the tailstock sleeve, they must be
oiled by the oil gun during every work shift. The surfaces of the cross slide
and the feeding ball screw must also be oiled by grease hand pump during
every work shift.
8. THE TRANSPORTATION
During transportation, some items should be noticed that when the
machine is lifted into or out of the packing wooden case, using two pieces
of steel pipes (Ф40) to insert the lifting holes on the left and the right
sides of the machine tool (see figure 4), it must be kept balance when it is
lifted or set down, never to be impacted, strenuously vibrated and
exceedingly tilted.
Number
Name
Model
Quantity
1
Taper ball bearing
7215AC/DB/P5
1
2
Taper ball bearing
7014AC/DB/P5
1
3
Angular contact ball
bearing
7203AC/P5/DB
1
4
Angular contact ball
bearing
7006AC/P5/DB
1
5
Thrust ball bearing
8102
1
