CNC210 Operating Manual
C.Altitude:1000 meters below
D. Radiation: Avoid the change of ambient temperature caused by direct sunlight or other
heat radiation
E.Installation position should be far away from the vibration source and inflammable and
explosive materials, away from the electromagnetic interference area
1.5 Impact of machine tools on the environment
When the machine idling,the noise is not more then 83db,no harmful gas or liquid emissions,
so there is any adverse impact on the environment.
2.Technical data
Item
Data(Metric)
Data(Inch)
Model Name
CNC210
CNC210
Max.swing over bed
210mm
8 1/4"
Max.swing over carriage
105mm
4 1/8"
Max. Machining length of work pieces
250mm
9 7/8"
Range of metric threads
0.25~4mm
0.00984-0.1575”
Range of imperial threads
6~80T.P.I
6~80T.P.I
Through spindle bore.
26mm
1.0236"
Spindle speed（DC stepless adjustment）
100~3000r/min
100-3000r/min
X travel
105mm
4 1/4"
Z travel
275mm
10 13/16"
Max.moving speed of X axis
（
step-motor
）
2000mm/min
78 3/4"/min
Max.moving speed of Z axis（step by step）
2000mm/min
78 3/4"/min
Taper of tail stock
MT2
MT2
Tail stock diameter
22mm
7/8"
Max.travel of tail stock
55mm
2 3/16"
Positioning accuracy
0.02mm
0.0008"
Re-positioning accurancy
0.02mm
0.0008"
Spindle proximal bounce
0.01mm
0.0004"
Motor
1.2kw
1.2Kw
Lubricating pump power（manual operation）
Water pump power
40w
40w
Tool-Post
electrical 4- station
Size of tool arbor
12mm
1/2"
Overall size（L X W X H）
1105 x 925 x
1145mm
43 1/2”x 36 3/7”x
45 1/9”
Net weight（about）
260kg
573lbs
3.Safety protection
The machine tool with some necessary safety equipment and warning signs, please read the
instructions carefully before operator,in order to avoid the damage or other machine operation
accident ,please fully understand all the operation method ans the signs.
