Component explanation
37
EN
Component explanation:
A
Monitor
B
Monitor controls
- Brightness / contrast
- Color
C
Camera control (only VIS 3xx)
with record and play-function (VIS 240 / VIS 340)
D
Camera head, waterproof:
VIS 3xx: pan- and tiltable
Color camera head 40 mm Ø
VIS 2xx: Miniature color camera head 26 mm Ø
E
Main power switch with the following functions:
- ON / OFF (System)
- Battery and system status
- Reset distance measurement (press shortly)
- Escape
F
Cardslot for memory card (VIS 240 / VIS 340)
G
Mini-USB-port (VIS 240 / VIS 340)
H
Power supply socket (18V/1,6A)
I
Video out
J
Accessory compartment 1
K
Rechargeable battery, extra
L
Power supply
M
Rechargeable battery, in use
N
Accessory compartment 2
O
Accessory compartment 3
